Cooler Specification

Socket compatibilityIntel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4
(Current socket compatibility applies to all coolers purchased since Q2 2022. For older coolers, please refer tothis chart.)

Height (without fan)160 mmWidth (without fan)150 mmDepth (without fan)135 mmWeight (without fan)980 g

Height (with fan)165 mmWidth (with fan)150 mmDepth (with fan)161 mmWeight (with fan)1320 g

MaterialCopper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating

NSPR183Max. TDPseeNSPR

Fan compatibility140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25

Scope of delivery

• 2x NF-A15 PWM premium fan
• 2x NA-RC7 Low-Noise Adaptor (L.N.A)
• NA-YC1 4-pin PWM splitter cable
• NT-H1 high-grade thermal compound
• SecuFirm2 mounting kit
• Noctua metal case-badge

Warranty6 Years

FAN SpecificationModel2x Noctua NF-A15 PWMBearingSSO2Max. rotational speed (+/- 10%)1500 RPMMax. rotational speed with L.N.A. (+/- 10%)1200 RPMMin. rotational speed @ 20% PWM (+/-20%)300 RPMMax. airflow140,2m/hMax. airflow with L.N.A.115,5m/hMax. acoustical noise24,6 dB(A)Max. acoustical noise with L.N.A.19,2 dB(A)Voltage range12 VMTTF> 150.000 h
